Kratke specifikacije
-
Accuracy
class B acc. to IEC 60751
class A acc. to IEC 60751
class AA acc. to IEC 60751 -
Response time
depending on configuration
iTHERM QuickSens: t90 = 1,5 s
iTHERM StrongSens: t90 = 9,5 s -
Max. process pressure (static)
at 20 °C: 40 bar (580 psi)
-
Operating temperature range
PT100 WW:
-200 °C … 600 °C
(-328 °F … 1.112 °F)
iTHERM StrongSens:
-50 °C … 500 °C
(-58 °F … 932 °F)
iTHERM QuickSens:
-50 °C … 200 °C
(-58 °F … 392 °F)
PT100 TF:
-50 °C … 200 °C
(-58 °F … 392 °F) -
Max. immersion length on request
48"
Područje primjene
It has been designed to meet the requirements of the Food & Beverages and Life Sciences industries and complies with the highest quality standards. It offers a variety of versions within a clearly segmented standard product. The result: Time and cost savings by simple and fast product selection. It offers many technical innovations: iTHERM QuickSens, StrongSens or QuickNeck. This leads to distinctive reduction of maintenance costs, improved product quality, process efficiency and safety.
Specially designed for use in hygienic and aseptic applications in the Food & Beverages and Life Sciences industries
Measuring range: –200 to +600 °C (–28 to +1 112 °F)
Pressure range up to 40 bar (580 psi)
Protection class: up to IP69K
Prednosti
-
User-friendly and reliable from product selection to maintenance
-
iTHERM inserts: globally unique, fully-automated production. Full traceability and consistently high product quality for reliable measured values
-
iTHERM QuickSens: fastest response times (t90s: 1.5 s) for optimum process control
-
iTHERM StrongSens: unsurpassed vibration resistance (> 60g) for ultimate plant safety
-
iTHERM QuickNeck – cost and time savings thanks to simple, tool-free recalibration
-
iTHERM TA30R: 316L terminal head for easier handling and lower installation and maintenance costs, and with highest IP69K rating
-
International certification: explosion protection e.g. ATEX/IECEx/FM/CSA and in compliance with hygiene standards according to 3-A, EHEDG, ASME BPE, FDA, TSE Certificate of Suitability
Videozapisi
Extended odabir
-
Vrhunski proizvodi
- Izuzetno funkcionalno i prikladno
Tehnička izvrsnost
Jednostavnost
-
Jednostavni proizvodi
- Jednostavno je odabrati, instalirati i rukovati
Tehnička izvrsnost
Jednostavnost
-
Standardni proizvodi
- Pouzdano, robustno i s malo održavanja
Tehnička izvrsnost
Jednostavnost
-
Specijalizirani proizvodi
- Dizajnirano za zahtjevne aplikacije
Tehnička izvrsnost
Jednostavnost
Promjenjivo
| FLEX odabir | Tehnička izvrsnost | Jednostavnost |
|---|---|---|
Fundamental odabir Udovoljite svojim osnovnim potrebama u mjernju |
Tehnička izvrsnost
|
Jednostavnost
|
Lean odabir Jednostavno upravljajte svojim osnovnim procesima |
Tehnička izvrsnost
|
Jednostavnost
|
Extended odabir Optimizirajte svoje procese s inovativnim tehnologijama |
Tehnička izvrsnost
|
Jednostavnost
|
Xpert odabir Ovladajte svojim najizazovnijim aplikacijama |
Tehnička izvrsnost
|
Jednostavnost
Promjenjivo |
Loading alternative products
Prethodnik
Uspješne priče
48 dokumenti
-
-
Tehničke informacije (TI)
TI Weld-in adapter, process adapter and flanges
Level, pressure and temperature measurement
EN HR 25/03/202415/09/202328/10/202130/07/202119/06/2020Jezik:
English
Verzije:
25/03/2024
Veličina datoteke:
1.1 MB
Naziv datoteke:
TI00426FEN_2524.pdf
-
-
-
Tehničke informacije (TI)
TI iTHERM ModuLine TM412
Trend-setting, modular resistance thermometer with spring loaded insert
for hygienic and aseptic applicationsEN HR 10/04/202401/08/202214/01/202131/10/201831/05/2018Jezik:
English
Verzije:
10/04/2024
Veličina datoteke:
2.8 MB
Naziv datoteke:
TI01348TEN_0624-00.pdf
-
-
-
Upute za uporabu (BA)
Modularni higijenski termometri
Univerzalni modularni termometri s RTD umetkom za higijensku primjenu
EN HR 20/01/2020Jezik:
Croatian
Verzije:
20/01/2020
Veličina datoteke:
592.7 KB
Naziv datoteke:
BA02023THR_0120.pdf
-
-
-
Upute za ugradnju (EA)
Installation Instructions iTHERM TM402, TM412
Imperial hygienic RTD thermometer
Jezik:
English
Verzije:
04/07/2017
Veličina datoteke:
821.1 KB
Naziv datoteke:
EA01221T09EN_0117.pdf
-
-
-
Ex sigurnosne upute (XA)
XA TR1x, Tx88, TSx310, Tx6x, TC1x, TPx100, TM411, TR24
Thermometers and inserts
Ex ia IIC T1...T6 Ga
Ex ia IIIC T<sub>200</sub> 85 °C...T<sub>200
</sub> 450 °C DaEN HR 30/08/202315/05/202331/07/2020Jezik:
English
Verzije:
30/08/2023
Veličina datoteke:
474.5 KB
Naziv datoteke:
XA02109TEN_0323-00.pdf
-
-
-
Ex sigurnosne upute (XA)
XA iTHERM TM411
Modular RTD assemblies for hygienic applications
0Ех ia IIC T6…T1 Ga Х
Ga/Gb Ех ia IIC T6…T1 Х
Еx ia IIIC T85°C…T450°C Da Х
Еx ia IIIC T85°C…T450°C Da/Db ХEN HR 10/07/202429/10/2021Jezik:
English
Verzije:
10/07/2024
Veličina datoteke:
434.8 KB
Naziv datoteke:
XA02760TEN_0224-00.pdf
-
-
-
Ex sigurnosne upute (XA)
XA iTHERM TM211, TPx100, TSx310
RTD/TC umetci i kabelski termometri
ATEX/IECEx:
Ex ia IIC T6 Ga
Ex ia IIC T6 Ga/Gb
Ex ia IIIC Txxx °C DaEN HR 30/03/202318/07/202210/07/201928/11/201628/11/2012Jezik:
Croatian
Verzije:
30/03/2023
Veličina datoteke:
458.2 KB
Naziv datoteke:
XA00100RHR_1823-00.pdf
-
-
-
Ex sigurnosne upute (XA)
TM411, TM412
Control Drawing
FM IS, NIEN HR 15/06/201801/12/2014Jezik:
English
Verzije:
15/06/2018
Veličina datoteke:
79.3 KB
Naziv datoteke:
XA01150TEN_0218.pdf
-
-
-
Ex sigurnosne upute (XA)
XA iTHERM TM411, iTHERM TM412
Modularni RTD sklopovi za higijenske primjene
ATEX, IECEx:
Ex ta/tb IIIC Txxx °C Da/DbEN HR 25/01/202416/05/202230/07/202007/05/201808/11/2012Jezik:
Croatian
Verzije:
25/01/2024
Veličina datoteke:
423.9 KB
Naziv datoteke:
XA01023THR_0524-00.pdf
-
-
-
Ex sigurnosne upute (XA)
TRxx, TCxx, TS211, iTHERM TS111, TM211, TPx100, TSx310, TM1x1, TM411, TM412
Thermometers and inserts
Ex nA IIC T6...T1 GcEN HR 31/07/2020Jezik:
English
Verzije:
31/07/2020
Veličina datoteke:
173.5 KB
Naziv datoteke:
XA02111TEN_0120.pdf
-
Pretražite rezervne dijelove prema broju na crtežu
60 spare parts & accessories
60 spare parts & accessories
60 spare parts & accessories
-
Spare parts kit gasket Da21/10x2EPDM
-
further parts
Narudžbeni kod71383294 -
-
Weld-in adapter G3/4 d=50, 316L, 3.1
-
further parts
Narudžbeni kod52018765 -
-
O-ring 14.9x2.7 VMQ, FDA, 5 pcs.
-
further parts
Narudžbeni kod52021717 -
-
Weld-in adapter G3/4, d=29, 316L, 3.1
-
further parts
Narudžbeni kod52028295 -
-
Weld-in adapter G3/4, d=55, 316L
-
further parts
Narudžbeni kod52001052 -
-
Weld-in adapter G3/4, d=55, 316L, 3.1
-
further parts
Narudžbeni kod52011897 -
-
O-ring 21.89x2.62 VMQ, FDA, 5 pcs.
-
further parts
Narudžbeni kod52014473 -
-
Weld-in adapter G1, d=60, 316L
-
further parts
Narudžbeni kod52001051 -
-
Weld-in adapter G1, d=60, 316L, 3.1
-
further parts
Narudžbeni kod52011896 -
-
O-ring 28.17x3.53 VMQ, FDA, 5 pcs.
-
further parts
Narudžbeni kod52014472 -
-
Weld-in adapter G1, d=53, 316L, 3.1
-
further parts
Narudžbeni kod71093129 -
-
Weld-in adapter G1, adjustable, 316L
-
further parts
Narudžbeni kod52001221 -
-
Weld-in adapter G1, adjustable,316L, 3.1
-
further parts
Narudžbeni kod52011898 -
-
Profile gasket 29x36x3.7, FDA, 5 pcs.
-
further parts
Narudžbeni kod52014424 -
-
Grip cap flexible yellow TPE
-
further parts
Narudžbeni kod71275424 -
-
Fixing kit cpl. TMT8x/7x USA(american)
-
further parts
Narudžbeni kod71044062 -
-
Spare parts kit sealing TA30A/TA30D
-
further parts
Narudžbeni kod71182602 -
-
Commubox FXA291 (Hardware)
-
further parts
Narudžbeni kod51516983 -
-
iTHERM Insert imperial TS212
-
further parts
Narudžbeni kodTS212- -
-
iTHERM ModuLine TT412
-
further parts
Narudžbeni kodTT412- -
-
iTEMP TMT162, Field Transmitter
-
further parts
Narudžbeni kodTMT162- -
-
iTEMP TMT31, Transmitter 4-20mA
-
further parts
Narudžbeni kodTMT31- -
-
iTEMP TMT36, Transmitter IO-Link
-
further parts
Narudžbeni kodTMT36- -
-
iTEMP TMT71, Transmitter 4-20mA
-
further parts
Narudžbeni kodTMT71- -
-
iTEMP TMT72, Transmitter HART
-
further parts
Narudžbeni kodTMT72- -
-
iTEMP TMT84, Transmitter PA
-
further parts
Narudžbeni kodTMT84- -
-
iTEMP TMT85, Transmitter FF
-
further parts
Narudžbeni kodTMT85- -
-
Display Unit Head Transmitter
-
further parts
Narudžbeni kodTID10- -
-
Terminal Head TA30A
-
further parts
Narudžbeni kodTA30A- -
-
Terminal Head TA30D
-
further parts
Narudžbeni kodTA30D- -
-
Terminal Head TA30P
-
further parts
Narudžbeni kodTA30P- -
-
Terminal Head TA30R
-
further parts
Narudžbeni kodTA30R- -
-
Terminal Head TA30S
-
further parts
Narudžbeni kodTA30S- -
-
iTEMP TMT82, Transmitter HART
-
further parts
Narudžbeni kodTMT82- -
-
Commubox FXA195
-
further parts
Narudžbeni kodFXA195- -
-
FieldCare SFE500
-
further parts
Narudžbeni kodSFE500- -
-
Fieldgate FXA42
-
further parts
Narudžbeni kodFXA42- -
-
iTHERM ModuLine TM412
-
further parts
Narudžbeni kodTM412- -
-
Spare Parts Kit Cover TA30R
Narudžbeni kodXPT0004- -
Configuration Kit TXU10
Narudžbeni kodTXU10-
