Differential pressure measurement

Continuous pressure measurement with differential pressure transmitter

Continuous pressure measurement with differential pressure transmitter
10 Proizvodi
Filter X icon
Deltabar PMD75B
F
L
E
X

  • Jednostavni proizvodi

  • Jednostavno je odabrati, instalirati i rukovati

Tehnička izvrsnost

Jednostavnost

  • Standardni proizvodi

  • Pouzdano, robustno i s malo održavanja

Tehnička izvrsnost

Jednostavnost

  • Vrhunski proizvodi

  • Izuzetno funkcionalno i prikladno

Tehnička izvrsnost

Jednostavnost

  • Specijalizirani proizvodi

  • Dizajnirano za zahtjevne aplikacije

Tehnička izvrsnost

Jednostavnost

Promjenjivo

FLEX odabir Tehnička izvrsnost Jednostavnost
  • F
  • L
  • E
  • X

Fundamental odabir

Udovoljite svojim osnovnim potrebama u mjernju

Tehnička izvrsnost
Jednostavnost
  • F
  • L
  • E
  • X

Lean odabir

Jednostavno upravljajte svojim osnovnim procesima

Tehnička izvrsnost
Jednostavnost
  • F
  • L
  • E
  • X

Extended odabir

Optimizirajte svoje procese s inovativnim tehnologijama

Tehnička izvrsnost
Jednostavnost
  • F
  • L
  • E
  • X

Xpert odabir

Ovladajte svojim najizazovnijim aplikacijama

Tehnička izvrsnost
Jednostavnost

Promjenjivo
Deltabar PMD75B Deltabar PMD75B - differential pressure transmitter
Deltabar PMD75B - differential pressure transmitter

Smart pressure transmitter which detects process anomalies like plugged impulse lines

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy Standard:
up to 0.05 %
Platinum:
up to 0.035 %
Max. measurement error Standard:
up to 0.05 %
Platinum:
up to 0.035 %
Measuring range 10 mbar...250 bar
(0.15 psi...3750 psi)
Process temperature -40°C...+110°C
(-40°F...+230°F)
Pressure measuring range 10 mbar...250 bar
(0.15 psi...3750 psi)
Main wetted parts 316L, AlloyC,
Tantal, Monel,
Gold
Max. process pressure 420 bar (6300 psi)
Material process membrane 316L, AlloyC,
Tantal,
Monel,
Gold
Wetted materials 316L,
AlloyC,
Tantal,
Monel,
Gold
Measuring cell 10 mbar...250 bar
(0.15 psi...3750 psi)
Deltabar FMD71 - Electronic differential pressure
F
L
E
X
Deltabar FMD71 - Electronic differential pressure Electronic differential pressure Deltabar FMD71
Electronic differential pressure Deltabar FMD71

Electronic differential pressure system utilizing two ceramic sensor modules and one transmitter

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy 0.075% of individual sensor,
"PLATINUM" 0.05% of individual sensor
Process temperature –25...+150°C
(–13...+302°F)
Pressure measuring range 100mbar...40bar
(1.5psi...600psi)
Process pressure / max. overpressure limit 60 bar (900 psi)
Material process membrane Ceramic
316L, AlloyC
Measuring cell 100 mbar...40 bar
(1.5 psi...600 psi)
Deltabar FMD72 - Electronic differential pressure
F
L
E
X
Deltabar FMD72 - Electronic differential pressure Electronic differential pressure Deltabar FMD72
Electronic differential pressure Deltabar FMD72

Electronic differential pressure system utilizing two metal sensor modules and one transmitter

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy 0.075% of individual sensor,
"PLATINUM" 0.05% of individual sensor
Process temperature –40...+125°C
(–40 ... +257°F)
Pressure measuring range 400 mbar...10 bar
(6 psi...150 psi)
Process pressure / max. overpressure limit 160 bar (2400 psi)
Main wetted parts 316L, Alloy C
Material process membrane 316L, AlloyC,
Measuring cell 400 mbar...10 bar
(6 psi...150psi)
Deltabar PMD55 - Differential pressure
F
L
E
X
Deltabar PMD55 - Differential pressure Differential pressure Deltabar PMD55
Differential pressure Deltabar PMD55

Differential pressure transmitter with metal sensor for measurement of pressure differences

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy 0,1%
"PLATINUM" 0,075%
Process temperature -40 °C...85 °C
(-40 °F...185 °F)
Pressure measuring range 10mbar...40bar
(0.15...580psi)
Main wetted parts 316L
Material process membrane 316L, AlloyC,
Measuring cell 10 mbar...40 bar
(0.15...580 psi)
Deltabar PMD55B - differential pressure transmitter
F
L
E
X
Deltabar PMD55B - differential pressure transmitter Deltabar PMD55B - differential pressure transmitter
Deltabar PMD55B - differential pressure transmitter

Smart transmitter with metal membrane for differential pressure monitoring in liquids and gases

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy Standard:
up to 0.075 %
Platinum:
up to 0.055 %
Measuring range 30 mbar...40 bar
(0.45 psi...600 psi)
Process temperature -40°C...+110°C (-40°F...+230°F)
Medium temperature range -40°C...+110°C
(-40°F...+230°F)
Pressure measuring range 30 mbar.... 40 bar (0.45 psi... 600 psi)
Main wetted parts 316L, AlloyC
Material process membrane 316L, AlloyC
Wetted materials 316L, Alloy
Measuring cell 30 mbar...40 bar
(0.45 psi...600 psi)
Deltabar PMD75 - Differential pressure
F
L
E
X
Deltabar PMD75 - Differential pressure Differential pressure Deltabar PMD75
Differential pressure Deltabar PMD75

Differential pressure transmitter with metal sensor for measurement of pressure differences

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy Standard: 0.05%
Platinum: up to 0.035%
Process temperature -40 °C...85 °C
(-40 °F...185 °F)
Pressure measuring range 10 mbar...250 bar
(0.15 psi...3750 psi)
Main wetted parts Alloy C276
316L
Monel
Tantalum
Material process membrane 316L, AlloyC,
Tantal,
Gold-Rhodium
Measuring cell 10 mbar...250 bar
(0.15 psi...3750 psi)
Deltabar FMD77 - Differential pressure
F
L
E
X
Deltabar FMD77 - Differential pressure Differential pressure Deltabar FMD77
Differential pressure Deltabar FMD77

Differential pressure transmitter with one diaphragm seal for level measurement

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy 0,075% + influence of diaphragm seal
Process temperature -40°C...400°C
(-40°F...752°F)
Pressure measuring range 100mbar...16bar
(1.5psi...230 psi)
Process pressure / max. overpressure limit 160bar (2400 psi)
Main wetted parts Alloy C276
316L
Monel
Tantalum
Max. measurement distance 160m (525ft) H2O
Material process membrane 316L, AlloyC,
Tantal,
Gold-Rhodium,
PTFE
Measuring cell 100 mbar...16 bar
(40 inH20...240 psi)
Deltabar FMD78 - Differential pressure
F
L
E
X
Deltabar FMD78 - Differential pressure Differential pressure Deltabar FMD78
Differential pressure Deltabar FMD78

Differential pressure transmitter with two diaphragm seals for differential pressure and level

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy 0,075% + influence of diaphragm seal
Process temperature -40°C...400°C
(-40°F...752°F)
Pressure measuring range 100mbar...40bar
(1.5psi ... 600 psi)
Process pressure / max. overpressure limit 160bar (2400 psi)
Main wetted parts Alloy C276
316L
Monel
Tantalum
Max. measurement distance 400m (1312ft) H2O
Material process membrane 316L, AlloyC,
Tantal,
Gold-Rhodium
PTFE
Measuring cell 100 mbar...40 bar
(40 inH2O...600 psi)
Deltabar PMD50 - product picture
F
L
E
X
New
Deltabar PMD50 - product picture Deltabar PMD50 - differential pressure transmitter
Deltabar PMD50 - differential pressure transmitter

Transmitter with metal membrane for measuring differential pressure, level and flow in liquids and gases

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Material process membrane 316L, AlloyC, Gold
Measuring cell 100 mbar...40 bar
(1.45 psi...580 psi)
Deltabar PMD78B
F
L
E
X
Deltabar PMD78B Deltabar PMD78B - differential pressure transmitter
Deltabar PMD78B - differential pressure transmitter

Minimizes ambient and process temperature effects on your measurement thanks to the TempC membrane

Loading price
Cijene privremeno nisu dostupne
from € 99'999'999.99
bookmark icon bookmark icon
Accuracy Standard:
up to 0.1 %
Process temperature -40°C...+400°C
(-40°F...+752°F)
Pressure measuring range 100 mbar...40 bar
(1.5psi...600 psi)
Main wetted parts 316L, AlloyC,
Tantal, Monel
PTFE, Gold
Material process membrane 316L, AlloyC,
Tantal,
Monel
PTFE
Gold
Measuring cell 100 mbar...40 bar
(1.5 psi...600 psi)

Application-specific product selection

Use our product finder to search for the right measuring devices, software or system components. The Applicator helps you to make an individual product selection according to your application area.

Go to product finder Go to Applicator

About differential pressure measurement

Proven in use in a wide range of applications in numerous industries: Differential pressure transmitters are used for the continuous measurement of differential pressures in liquids, vapors and gases. They are suitable for all types of media, both in standard applications and for applications with high process pressures and temperatures.

Measuring principle

The principle of differential pressure measurement is based on measuring the difference between two pressures. The differential value is output as a measurement result using a differential pressure transmitter.

Benefits

  • Universal differential pressure transmitters for flow, level and filter applications
  • Process temperatures from -70 to +400 °C are possible with diaphragm seals
  • Improved process availability and minimization of safety risks thanks to electronic differential pressure system
